6574TQ 4 Core 4mm² Marine Cable BS6883

6574TQ 4 CORE 4MM² MARINE & OFFSHORE CABLE BS6883 WF404 BLACK LSZH


OVERVIEW

657TQ marine and offshore cables. Non-armoured cable, suitable for power, control and lighting for fixed installations in all areas aboard ships and offshore units, including accommodation and open decked areas exposed to the elements. The cable should be installed where there is no risk of mechanical damage.

Intended for use in commercial applications.

STANDARDS

BS6883

IEC60332-1

IEC60332-3-22

IEC60754-1, 2

IEC61034-1, 2

CONSTRUCTION

Conductor: Tinned copper conductor

Insulation: Ethylene propylene rubber (EPR)

Sheath: Low smoke zero halogen (LSZH) SW4

Sheath Colour: Black

CHARACTERISTICS

Voltage Rating: 600/1000 Volts

Temperature Limits: -40°C (fixed installation) to +90°C

Minimum Bending Radius: As per cable manufacturer datasheet

Should not be installed at temperatures below -15°C

CORE IDS

White and Black numbers

Black outer sheath

Product Code 6574TQ4

Colour Black

Conductor 4mm²

Stranding 7/0.85

Cores 4

Weight 360kg/km

Diameter 13.9mm

UKOOA WF404
